Extron Electronics TLP 710CV User Guide User Manual
Page 36
If you are working on the project, leave the
Open as read-only
box unchecked.
Click
Open
to open the file. The project opens in GUI Configurator.
z
Download an Existing Project from a Panel
— Clicking
OK
opens a dialog box
that allows you to download a file that has been uploaded to a touchpanel.
Figure 28.
GUI Configurator Download Project Dialog Box
In the dialog box that opens, enter the IP address of the touchpanel and use the
Browse
button to navigate to a folder where the file will be saved.
Check
Open the project
and
Close Download Manager
.
Click
OK
. The project is downloaded to your computer and opens in GUI Configurator.
TLP 710CV • Configuration Software
30
