Time Screen
Exit
Down Up
Month: 06
Down Up
Hours: 13
Down Up
Day: 06
Down Up
Minutes: 32
Down Up
Year: 2011
Main
Volume
Time
Network
Video
Figure 13. Time Screen
Use the Down or Up buttons to adjust the Month, Day, Year, Hours, and Minutes.
NOTE: The Hours value uses the 24-hour clock. For 10 am, set hours to 10; for 10 pm, set
hours to 22.
Network Screen
Exit
Main
Volume
Time
Network
Video
IP Address
192.168.254.254
Subnet Mask
255.255.0.0
DHCP
Off
MAC: 00-05-A6-07-3A-55
1 2 3
4 5 6
7 8 9
0 . Clear
Figure 14. Network Screen
To set the IP Address or Subnet Mask, press the appropriate button. When one of the buttons
is selected, an on-screen keypad appears that allows the user to select digits between 0 and 9,
“Clear,” or “.” (dot).
NOTE: The factory default IP address for the TLP 710CV is 192.168.254.254 and the
default subnet mask is 255.255.0.0. Consult your IT department to ensure these
addresses are correctly assigned.
Toggle between On and Off to enable or disable Dynamic Host Configuration Protocol (DHCP).
This determines whether the unit will have a permanent IP address or will have one provided by
the network, when required. The default setting is Off.
TLP 710CV • Initial Configuration and Calibration 20
