Installation

Overview

This section provides an overview of the main steps required to install the TLP 710CV and
provides links to more detailed explanations of each step.

You can also visit the TouchLink

touchpanel site at

www.extron.com/touchlink

for further assistance in the setup and

operation of the TLP 710CV, or to enroll in online training. For additional assistance,
contact

your nearest Extron office

The instructions provided in this guide are for experienced installers. To avoid damaging the
furniture, Extron recommends that the opening in the table for the TLP 710CV should be cut
only by a licensed and bonded craftsperson.

Planning

Decide what the system requires

and ensure that there is enough space for all the

components of the system.

Collect the tools

needed to complete the installation.

Open the shipping container and

verify that all the components

are present.

Mounting the TLP 710CV

Decide how to cut the hole

and obtain the proper cutout dimensions or a router

template.

Cut a hole in the furniture.

Preparing and Installing the AAP Assembly

Run but do not connect the cables

for the AAPs and TLP 710CV.

Install cable retractors

, if required.

If required,

install the power module

Install AAPs

. Loosely fasten all AAPs to the AAP assembly and install cables.

Install the AAP assembly

into the Cable Cubby enclosure and tighten all AAPs.

Mount and secure the TLP 710CV frame

into the furniture opening.

Connecting the Touchpanel

Connect the TLP to the PoE power supply

and connect the power supply to a network

router.

NOTE: Extron recommends using the PoE power supply (provided). Alternatively, it is

possible to connect a 12 VDC power supply (not provided).

(Optional) If you are not using PoE, mount and

connect a 12 VDC power supply

the TLP 710CV and connect the TLP 710CV directly to a network router.

(Optional) For the video monitoring capabilities,

connect the MTP transmitter

input.

TLP 710CV • Installation Overview
