MKP 1000/1200 • Introduction
Introduction
MKP 1000/1200
2
Chapter Two
Installation and Connection
Installing the Keypad
Panel Mount
Connecting the Keypad
Making Cables
1-4
location (a keypad, a touch control screen, a PC or other RS-232 device)
will tie the video camera to each of the large screen projectors in the other
rooms and possibly to a VTR in the media room. The global preset
overrides the local (room) selection. When finished, make a selection
from the local keypad.
This manual covers four major steps for making an MKP keypad
operational. These are explained in Chapters 2 and 3.
1. Installing the MKP keypad in a wall, podium, or desk.
2. Connecting the keypad to a matrix switcher.
3. Programming each keypad for its room number or its
output device.
4. Operating the MKP keypad to select the input sources for
that room, or that output device.
