Command
ASCII Command
(host to unit)
Response
(unit to host)
Additional Description
Voltage and Potentiometer Adjustment
Set
the
maximum
voltage
output
level
E
V*
X$
VLCM
}
Vlcm
•
V
X$]
Vol
X!]
Set the maximum voltage output level.
(
X$
= 0.04 to 10.00 V; default is 10 V.)
The volume status (
X!
) is reported even
if there is no change in volume.
NOTE: The device control mode must be set to voltage before this command can be used.
View
maximum
voltage
output
level
E
VVLCM
}
Vlcm
•
V
X$]
X$
is returned in four digits with no
decimal point.
Set
the
potentiometer
maximum
resistance
output
E
P*
X$
VLCM
}
Vlcm
•
P
X$]
Vol
X!]
Sets the maximum resistance output
on the wiper ( ) pin. (
X$
= 0.00 to
10.00 kilohm; default is 10 kilohm.)
The volume status (
X!
) is reported even
if there is no change in volume.
NOTE: The device control mode must be set to potentiometer before this command can be used.
View
the
potentiometer
maximum
resistance
output
E
PVLCM
}
Vlcm
•
P
X$]
X$
is returned in four digits without a
decimal.
Modes
Set
control
mode
E
M*
X%
VLCM
}
Vlcm
•
M
X%•]
Vol
X!]
Control mode status (
X%
)
0 = potentiometer (default)
1 = voltage
View
control
mode
E
MVLCM
}
Vlcm
•
M
X%•]
Set
inverse
mode
E
I*
X@
VLCM
}
Vlcm
•
I
X@•]
Vol
X!]
Inverse mode status (
X@
)
0 = Off (default)
1 = On
View
inverse
mode
E
IVLCM
}
Vlcm
•
I
X@•]
If Inverse mode is off, returns 0;
if Inverse mode is on, returns 1.
Set
soft
start
mode
E
S*
X@
VLCM
}
Vlcm
•
S
X@•]
Soft start mode status (
X@
)
0 = Off
1 = On (default)
View
soft
start
mode
E
SVLCM
}
Vlcm
•
S
X@•]
Set
soft
start
delay
E
D*
X(
VLCM
}
Vlcm
•
D
X(]
Soft start delay —
X(
ms per volume
step 40 ms (default) to 200ms
View
soft
start
delay
E
DVLCM
}
Vlcm
•
D
X(]
Set
auto
mute
mode
E
A*
X@
VLCM
}
Vlcm
•
A
X@•]
Auto mute mode status (
X@
)
0 = Off
1 = On (default)
View
auto
mute
mode
E
AVLCM
}
Vlcm
•
A
X@•]
Set
volume
taper
mode
E
L*
X^
VLCM
}
Vlcm
•
L
X^•]
Vol
X!]
Volume taper mode status (
X^
)
0 = Linear
1 = Logarithmic
View
volume
taper
mode
E
LVLCM
}
Vlcm
•
L
X^•]
