4-7 MAV 44 / 48 / 84 / 88 Matrix Switchers • Remote Operation
Command/response table for SIS commands (cont’d)
Command ASCII Command Response Additional description
(host to switcher) (switcher to host)
IR receiver enable
Enable IR receiver 0*65# IRdisable*0 Enable the IR receiver (allow
control by the IR 501).
Disable IR receiver 1*65# IRdisable*1 Disable the IR receiver (do not
allow control by the IR 501).
Read IR receiver enable 65# X10 0= enable, 1 = disable (default).
Global presets
Save current configuration as preset X11
,
Spr X11 Command character is a comma.
Example: 8
,
Spr08 Save current ties as preset 8.
Recall a preset X11
.
Rpr X11 Command character is a period.
Example: 5
.
Rpr05 Recall preset 5, which becomes
the current configuration.
View global preset configuration Esc X11 VC X2
1 • X2
2 • X2
3 •...• X2
n •Vid• X2
1 • X2
2 • X2
3 •...• X2
n •Aud
n is the highest output number
for this model switcher. Show
preset
X11 ’s video and audio
configuration. Show the video
input tied to n sequential outputs
and then the audio input tied to
n sequential outputs.
Response description: Video input # (I#) assigned to Output # (O#1)•I# assigned to O#2...I# assigned to O#8•Vid•
Audio I# assigned to O#1•I# assigned to O#2...I# assigned to O#8•Aud
Example (MAV 88 AV): Esc 4VC
1 Output:
Response = tied input:
Input 5 video tied to output 2
2 3 4 5 6 7 8 1 2 3 4
6•5•6•8•3•3•1•0•Vid•8•1•1•1•8•8•8•8•Aud
5 6 7 8
No tied input Audio input 8 tied to output 5
Each position shown in the response is an output: left = output 1, right = output 8. The number in each position is the
input tied to that output. Global preset 4 makes the following ties:
Video — Input 6 is tied to outputs 1 and 3; input 5 to output 2; input 8 to output 4; input 3 to outputs 5 and 6; and
input 1 to output 7. No input is tied to output 8.
Audio — Input 8 is tied to outputs 1 and outputs 5 through 8; input 1 to outputs 2 through 4.
Example (MAV 44 V): Esc 4VC
Output:
Response = tied input:
Input 1 tied to output 2
1•1•0•2•Vid
1 1 1 1
Front panel security lockout (Executive mode)
Lock front panel 1X Exe1 Enable executive mode.
Unlock front panel 0X Exe0 Disable executive mode.
Read front panel lockout status X X8 1= executive mode on,
0 = executive mode off.
