Page 10: Features of the ipl t sfi244 include, 12 vdc, 1 a desktop power supply, Rj-45 ethernet receptacle, Two (2) rs-232 serial ports, Four (4) flex i/o ports, Four (4) i/r ports, Six (6) ethernet control ports
4
IPL T Series • Introduction
IPL T SFI244
Features of the IPL T SFI244 include:
z
z
12 VDC, 1 A desktop power supply
z
z
RJ-45 Ethernet receptacle
z
z
Two (2) RS-232 serial ports
z
z
Four (4) flex I/O ports
z
z
Four (4) I/R ports
z
z
Six (6) Ethernet control ports
Extron
IPL T RLY4
Relay box
Lighting
System
COM1
TX
RX
TX
RX
COM2
LAN
00-05-A6-xx-xx-xx
POWER
12V
.5A
MAX
FLEX I/O
2
1
3
4
1
IR
2
3
4
G
S
G
S
G
S
G
S
Screen
Control
Extron
IPL T SFI244
Ethernet Control
Interface
RS-232
RS-232
DVD 1
VCR/
DVD 2
Extron
IR Emitters
Projector
Ethernet
TCP/IP
Network
Motion
Detector
Extron
MLS 103 SV
S-video & Audio
Switcher
DSS Receiver
NO C NC
NO C NC
NO C NC
NO C NC
RELA
Y 1
RELA
Y 2
RELA
Y 3
RELA
Y 4
MLS 100 Series
MediaLink Switcher
AUX/MIX
LEVEL
INPUT SELECT
1
2
3
4
GlobalViewer
®
A/V Resource
Management and
Remote Control
Application
Figure 2.
Typical IPL T SFI244 Controller Application
IPL T CR48
Features of the IPL T CR48 include:
z
z
12 VDC, 1 A desktop power supply
z
z
RJ-45 Ethernet receptacle
z
z
Four (4) contact closure input ports
z
z
Eight (8) relay ports
z
z
Six (6) Ethernet control ports
