1-3 DDS 100 Introduction
• Input — Includes BNC inputs for RGsB (sync on green), RGBS
(composite sync) and RGBHV. Also includes a second set of
connectors for attaching a local monitor.
• LCD menu display — Provides access to several menus that control
the image display.
• Memory presets — Uses 130 memory locations to store presets that
include size, zoom, pan, centering, and filter control settings for
various scan rates. The user can specify 30 of these presets, and
the remainder were set at the factory. The DDS 100 digital display
scaler automatically loads the control settings from the preset
associated with the scan rate of the input video signal.
• Output — Outputs video as RGsB, RGBS, or RGBHV. BNC connectors
and a 15-pin HD connector are provided, although only one
output format can be used at any one time.
• Output resolutions — Supports the following output resolutions:
• 640 x 480 (VGA)
• 800 x 600 (SVGA)
• 832 x 624 (Macintosh)
• 852 x 480 (plasma)
• 1024 x 768 (XGA)
• 720p (HDTV)
• 848 x 480 (plasma)
• 1280 x 768 (plasma)
• 1360 x 765 (plasma).
• Power supply — Includes an internal, 100-240 VAC, 50/60 Hz, auto-
switchable power supply.
• RS-232 control — Provides control for third-party remote control of
features and functions that can be programmed by using Extron’s
SIS™ (Simple Instruction Set™) or Extron’s control software for
Windows®.
