B-5 DDS 100 Reference Information
8. If the DDS 100 is rack mounted, remove the power cable from the
unit, and reattach the rack mount brackets. Reattach the unit to
the rack, and reconnect the power cord and input and output
cables.
If you choose to check the power before putting the cover back on, make
sure that tools and hands are outside the DDS 100, and then connect
the power cord to the unit and to an AC source. The unit should power
up normally. Unplug the AC power cord, and follow steps 5 – 8 above.
Part Numbers
DDS 100 part numbers
Extron Part Part #
DDS 100 60-305-01
VSC and DDS Control Program 29-038-01
DDS 100 User’s Manual 68-457-01
Related part numbers
Extron Part Part #
*BNC 75-ohm termination plug (2) 26-300-01
* These items are supplied with the DDS 100.
BNC cables
Extron SHR BNC cables are super-high resolution cables. Extron
recommends using high-resolution BNC cables for signals with scan
frequencies of 15 — 125 kHz to achieve maximum performance.
Bulk cable
Extron Part Part #
SHR bulk cable
Bulk SHR-1, 500’ 22-098-02
Bulk SHR-1, 1000’ 22-098-03
Bulk SHR-4, 500’ 22-099-02
Bulk SHR-5, 500’ 22-100-02
BNC SHR crimp connectors, qty. 50 100-075-51
BNC-4 Mini-HR Bulk Cable
Bulk BNC 4-500’ HR 22-032-02
Bulk BNC 4-1000’ HR 22-032-03
BNC 5 Mini-HR Bulk Cable
Bulk BNC 5-500’ HR 22-020-02
Bulk BNC 5-1000’ HR 22-020-03
BNC 5 Plenum Mini-HR B ULK Cable
Bulk BNC 5-500’ HRP 22-103-02
Bulk BNC 5-1000’ HRP 22-103-03
Install Plenum Bulk Cable
Bulk Install Plenum, 500’ 22-111-03
Bulk Install Plenum, 1000’ 22-111-04
Continued on the next page
