3-3 DDS 100 Operation
12 The Freeze button was pressed. The image frozen/controls locked
screen disappears, and the frozen image is released.
13 Entry into path E . The cursor Up and Down buttons were
pressed together, or the executive mode RS-232 command was
issued.
14 Executive mode enabled screen, which appears for four seconds
and then loops back to the default cycle.
15 Executive mode disabled screen, which appears for four seconds
and then loops back to the default cycle.
E Path to the executive mode screens.
F Path to the image frozen/controls locked screen.
M Path to the zoom/size/pan controls menu screens.
If the signal is out of range, or if there is no video input, there is no
video output through the output device.
Navigating the Menu Screens
Using the Menu and Next buttons
Figure 8, on the next page, shows the DDS 100 flow chart. The default
cycle, zoom, size, and centering/pan screen boxes have dashed lines to
indicate that there are alternate screens for executive mode and for
minimum/maximum values exceeded.
When the Next button is used to step through menu screens, an
alternate screen might be displayed, depending on previous adjustments
or selections. For example, if the zoom screen adjustment exceeds the
minimum or maximum limit, the applicable alternate zoom screen is
displayed. The zoom is left in that state. The next time the zoom screen
is entered, the applicable alternate zoom screen is displayed again.
You cannot enter any menu screens if the input signal is out of
range. You can enter the menu screens if there is no input signal.
• To enter the zoom/size/pan controls menu from the default cycle
( 1 , 2 ), press and release the Menu button on the front panel.
• To step through the menu screens ( 3 , 4 , 5 , 6 ) and loop back to
the zoom/size/pan controls menu entry screen, press and release
the Menu button repeatedly.
• To return to the default cycle screens, press and release the Next button
from the exit menu ( 7 ). Or, wait eight seconds without pressing
any buttons from any menu screen; a time-out will occur, and the
default cycle screens will appear.
• To step through the menu screens ( 3 , 8 , 9 ) and loop back to the
menu entry screen (
10
), press and release the Next button from
within a menu screen.
• To exit to the next menu entry screen from within any menu, press and
release the Menu button.
