Specifications, cont’d
DDS 100 Specifications A-2
Specifications
Video input
Number/signal type ................... 2 RGBHV, RGBS, RGsB
Connectors .................................... 2 x 5 BNC female (5 for input, 5 for passive local monitor output)
Maximum level ............................ Analog ....... 2.0V p-p with no offset
Impedance .................................... 75 ohms or High Z (switch selectable)
Horizontal frequency .................. Autoscan 24 kHz to 100 kHz
Vertical frequency ....................... Autoscan 50 Hz to 120 Hz
Resolution range .......................... Autoscan 560 x 384 to 1600 x 1280
Video processing
Digital sampling .......................... 24 bit, 8 bits per color; 80 MHz standard
Colors ............................................ 1.6 million
Horizontal filtering ...................... 4 levels
Vertical filtering ........................... 10 levels
Video output
Number/signal type ................... 1 RGBHV, RGBS, RGsB
Connectors .................................... 5 BNC female or 1 VGA-XGA 15-pin HD female
Minimum/maximum levels ...... 0.0V to 0.7V p-p
Impedance .................................... 75 ohms
Scaled VGA resolution ................ 640x480, 480p, 800x600, 832x624, 848x480, 852x480, 1024x768, 720p,
1280x768, 1360x765
Sync
Input type ..................................... Autodetect RGBHV, RGBS, RGsB, RsGsBs
Output type .................................. RGBHV, RGBS, RGsB
Input level ..................................... 1.5V to 5.0V p-p
Output level .................................. 5.0V p-p
Input impedance .......................... 75 ohms or High Z (switch-selectable)
Output impedance ....................... 75 ohms
Polarity .......................................... Negative
Control/remote — scaler
Serial control port ........................ 1 RS-232, 9-pin female D connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations .... 2 = TX, 3 = RX, 5 = GND
Program control ........................... Extron’s control program for Windows®
Extron’s Simple Instruction Set™ — SIS™
General
Power ............................................. 100VAC to 240VAC, 50/60 Hz, 40 watts, internal, auto-switchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, non-condensing
Rack mount ................................... Yes, with included rack ears
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 17.5" W x 9.4" D (1U high, full rack width)
4.4 cm H x 44.4 cm W x 23.9 cm D
Product weight ............................. 5.6 lbs (2.5 kg)
Shipping weight .......................... 9 lbs (4.1 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International Safe Transit Association)
