Operation pHotoFlex / pHotoFlex Turb
28 ba75491d04 07/2006
Menus and dialogs The menus for settings and dialogs in courses contain further sub-
menus. The selection is made with the <
▲> <▼> keys.
The current selection is displayed in reverse video.
! Menus
The name of the menu is displayed at the upper edge of the frame.
Menus are opened by confirming with . Example:
! Settings
Settings are indicated by a colon. The current setting is displayed on
the right-hand side. With , the selection of the
possible settings is opened. Subsequently, the setting can be
changed with <
▲> <▼> and .
Example:
! Functions
Functions are designated by the name of the function. They are im-
mediately carried out by confirming with .
Example: display the Calibration record function
(in the pH & ORP / Calibration menu).
! Messages
Information or instructions are marked by the
i symbol. They can-
not be selected.
Photometry
Turbidity
pH & ORP
System
Info
Configuration
Language : Deutsch
Beep : Off
Illumination : On
Contrast : 48 %
Temperature unit : °C
Switchoff time : 30 min
System
Calibration record
Cal. type : AutoCal
TEC
Calibration interval : 007 d
Unit for slope : mV/pH
: i 2.00 4.01 7.00 10.01
pH & ORP
