Dissolved Oxygen Transmitter
Service Menu - Detailed
The "Service Menu", a submenu in "Converter setup", is intended for MJK
and other authorized service personnel during installation, calibration,
commissioning, operation, monitoring and maintenance.
Averaging
Units
mA output
Converter setup
20 mA output
20 mA =
25.00 mg/l
Back Select
OK
D.O. Units
%
mg/l
ppm
Back Select
OK
Averaging
Units
mA output
Cleaning
High alarm
Low alarm
Sensor error
Status
Factory settings
Service menu
Back Select
OK
4mA output
4 mA =
00.00 mg/l
Back Select
OK
When ”n/a” is displayed, the
menu is not available or not
applicable
Yes
Enable mA output?
Yes
No
Back Select
OK
Averaging
0001 sec
(from 1 sec to 120 min)
Back Select
>
Temperature unit
°C
°F
Back Select
OK
Temperature
This menu is for display only.
Clean now
Yes
No
Back Select
OK
Reset Maintenance
Yes
No
Back Select
OK
Maintenance
Runtime 1000 hour
Count
500
Back Select
OK
Clean now
Select cleaning interval
060 Min
(20 - 255 Min)
Back Select
>
Cleaning
Interval
Use DI to clean
Clean now
Maintenance
Back Select
OK
Interval
Off
On
Back Select
OK
Use DI to clean
Interval
Maintenance
DI function
NO
NC
Back Select
OK
Use DI to clean
No
Yes
Back Select
OK
Delay
00100 ms
Back Select
>
Electro-mechanical relay
Opto relay
Not in use
Back Select
OK
Cleaning time
005 sec
Back Select
OK
Cleaning time
005 sec
Back Select
OK
Measurement delay
10 sec
Back Select
OK
GB Oxix menuer #1 Converter setup 1
FW: 841013-009, 846001-002, 841513-009
Page 2 of 7 15. september 2008
All parameters can be read without any restrictions, but certain parameters
can only by changed after a password has been typed.
Sensor Data
Sensor Calibration
Converter SW. Version.
Product data
Reset Counter Time
Internal meas. & cal.
Calibrate mA
Test Primary value
Read eventlog
Comunication log
Back On Stock
Autodetect sensor type
Main supply frequency
Back Select OK
Sensor data
Sensor serial number
30487
Sensor software version
2
Back OK
Converter SW version
Converter 846001-002
195
Bootload 840020-002
684
Back
Product data
Product ID
000000000000
Back Select >
HW type no
0510305004
Back Select >
Track no
00000
Back Select >
Product type no
00000206305
Back Select >
Set actual measurement
10,20 mg/l
Back Select
OK
Sensor calibration
Sensor calibration
1 point calibration
2 point calibration
Cancel
Back Select
OK
OK
Clear calibration
No
Yes
Back Select
OK
Confirm zero oxygen
No
Yes
Back Select
OK
1 point
2 point
Calibrate Vcc
Calibrate V_ref
Back Select OK
Internal meas. & cal.
View Vcc
- - - -
Back Select OK
Calibrate Vcc
- - - -
Back Select >
View V_ref
- - - -
Back Select OK
Calibrate Vref
- - - -
Back Select >
Reset counter time
Reset Counter 1
System Runtime 2304
Since Reset 2304
Runtime (days)
0
Back Select OK
Set actual measurement
10,20 mg/l
Back Select
OK
Type password
00000
Back Select >
Service menu
GB Oxix menuer #1 Service menu 1
FW: 841013-009, 846001-002, 841513-009
Page 5 of 7 15. september 2008
Sensor Data
Sensor Calibration
Converter SW. Version.
Product data
Reset Counter Time
Internal meas. & cal.
Calibrate mA
Test Primary value
Read eventlog
Comunication log
Back On Stock
Autodetect sensor type
Main supply frequency
Back Select OK
Sensor data
Sensor serial number
30487
Sensor software version
2
Back OK
Converter SW version
Converter 846001-002
195
Bootload 840020-002
684
Back
Product data
Product ID
000000000000
Back Select >
HW type no
0510305004
Back Select >
Track no
00000
Back Select >
Product type no
00000206305
Back Select >
Set actual measurement
10,20 mg/l
Back Select
OK
Sensor calibration
Sensor calibration
1 point calibration
2 point calibration
Cancel
Back Select
OK
OK
Clear calibration
No
Yes
Back Select
OK
Confirm zero oxygen
No
Yes
Back Select
OK
1 point
2 point
Calibrate Vcc
Calibrate V_ref
Back Select OK
Internal meas. & cal.
View Vcc
- - - -
Back Select OK
Calibrate Vcc
- - - -
Back Select >
View V_ref
- - - -
Back Select OK
Calibrate Vref
- - - -
Back Select >
Reset counter time
Reset Counter 1
System Runtime 2304
Since Reset 2304
Runtime (days)
0
Back Select OK
Set actual measurement
10,20 mg/l
Back Select
OK
Type password
00000
Back Select >
Service menu
GB Oxix menuer #1 Service menu 1
FW: 841013-009, 846001-002, 841513-009
Page 5 of 7 15. september 2008
