11
Dissolved Oxygen Transmitter
GB Oxix Manual 080915
FW: 841013-009, 846001-002, 841513-009
Features
Flexible Installation
MJK’s modular design allows up to 300 meters (950ft.) between the sensor
and the converter, and the Display Unit can be mounted up to 1000 m
(3000 ft.) from the signal converter with ordinary twisted wires.
ll
RS-
485
RS-
485
RS-
485
Max. 1000 m
1 pc. Oxix Converter
with display (206505)
3 pcs. Oxix without display (206508)
4 pcs. Oxix sensors (206510)
ll ll
300 m
Max.
One Display Unit can control up to four MagFlux ® flow meters, SuSix ® trans-
mitters and/or Oxix ® transmitters for greater economy, space savings and an
improved overview of the multiple measurement values.
Simple to Operate
The Oxix ® Display Unit has a mobile phone-like menu structure and can dis-
play text in several selectable languages.
PC Connection
Oxix ® allows downloading setup configurations, uploading new instrument
software updates and display customization. The onboard data logger cap-
tures 20.000 readings which are displayed as an electronic graph and can be
retrieved as a CSV file on a PC. This connectivity is achieved with a common
USB port and the free MJK Field Link software.
