System configuration examples – Xylem Oxix Dissolved Oxygen Transmitter User Manual
Page 31
31
Dissolved Oxygen Transmitter
GB Oxix Manual 080915
FW: 841013-009, 846001-002, 841513-009
7. System Configuration Examples
MJK Oxix
®
transmitters share communication protocols with other MJK prod-
ucts like the MJK Magflux
®
flow meter and the MJK Connect data transmitter,
and can also share display units. This section illustrates two configuration
examples and includes cable connections and part numbers.
Magflux
®
with blind lid and Oxix
®
with display unit
Oxix
®
with blind lid, Magflux
®
with blind lid and a remote display unit
