16 GB Oxix Manual 080915
FW: 841013-009, 846001-002, 841513-009
Dissolved Oxygen Transmitter
Oxix ® Sensor
Dissolved oxygen saturated
0 - 30.0 mg/l or ppm (parts per million)
0 - 120 %
Measurement principle Optical, near infra-red fluorescence (l
in
= 475 nm, I
out
= 600 nm)
Sensor check Automatic self-diagnostics
Pressure 6 bar (100 psi)
Materials Boby and Head: PU, PVC, silicone, epoxy and stainless steel 316 SS
Optical lens: Sapphire
O-ring: Viton
Cable: PUR
Cleaning system Built-in air or water jet
Cable 4 x 0,326 mm 2 , shielded, outer diameter Ø 5.0 mm (22 AWG)
Cable length 10 m (33 ft.), can be extended up to 600 mm
Response time t
90
less than 1 second, t
95
less than 60 second
Flow velocity No flow required
Power supply 12 V DC (10 -16 V DC), approx. 10 mA
Output RS 485, 9600 baud, 2-wire
Accuracy Better than 1% of actual reading (0,02 mg/l)
Resolution Better than 0,02 mg/l
Temperature range 0 - 60 ºC
Temperature compensation 0 - 50 ºC
Enclosure rating IP 68 to IEC 529 (10 m), NEMA 6
Dimensions 50 x 130 mm (diameter x length)
Mounting
1,5 inch NPT thread
0,25 inch NPT thread for jet spray cleaning tube
Weight 0,77 kg (1.7 lbs)
