Dissolved Oxygen Transmitter
GB Oxix Manual 080915
FW: 841013-009, 846001-002, 841513-009
Status
The "Status" option provides an overview of the in- and output status.
Type password
00000
Back Select >
Service menu
Pending errors
xxx
xxx
Back Select OK
Factory setting
Recover factory settings
Cancel
Default
Force to SuSix
Force to Oxix
Back Select OK
Status
DO 1 [ x ] Selected function
DO 1 [ \ ] Selected function
DI [ ] Selected function
mA output 10,234 mA
Back Select OK
Pending warnings
xxx
xxx
Back Select OK
Pending information
xxx
xxx
Back Select OK
Pending alarms
xxx
xxx
Back Select OK
GB Oxix menuer #1 Converter setup 3 FW: 841013-009, 846001-002, 841513-009 Page 4 of 7 15. september 2008
The check boxes can contain four different characters:
X A cross (X) in a check box indicates an active state
/ A blinking forward slant (/) in a check box indicates that the input/
output is in the process of being activated. Eventually it turns into a
steady X.
