ViSolid
®
700 IQ (SW) Commissioning
3 - 15 ba76040e02 07/2013
Carrying out settings Switch to the main settings menu from the measured value display with
. Then navigate to the setting menu (setting table) of the sensor.
The exact procedure is described in the relevant IQ S
ENSOR N ET
system operating manual.
Measuring mode
SiO2:
Measuring ranges
The setting
AutoRange =
automatic
changeover of the
measuring range
can be selected in all
measuring modes.
 0 ... 400.0 mg/l
 0 ... 4000 mg/l
 0 ... 25000 mg/l Measuring ranges for the
Mtrx.type1:mg/l SiO2 measuring mode
 0 ... 400.0 ppm
 0 ... 4000 ppm
 0 ... 2.500 % Measuring ranges for the
Matrix type1:% SiO2 measuring mode
 0 ... 4000 mg/l
 0 ... 40000 mg/l Measuring ranges for the
Mtrx.type2:mg/l SiO2 measuring mode
 0 ... 4000 ppm
 0 ... 4.000 %
 0 ... 30.00 % Measuring ranges for the
Matrix type2:% SiO2 measuring mode
Setting Selection/values Explanation
