Relay outputs System 182
6 - 4 ba76025e01 02/2012
6.2.3 Setting outputs
Proceeding: setting an
output
Note
To accept all settings, you have to highlight the Save and quit menu
item at the lower end of the setting table and press
g
. If you exit the
setting table via
m
,
e
/Quit or the Quit menu item, all changes are
ignored.
1 Open the SETTINGS menu with
s
.
2 Using
w
and
g
, select and confirm the Relay output Rx
menu item (corresponding to sensor 1, 2 or 3).
3 Confirm the selection Set output with
g
.
The setting table of the output is displayed.
4 Edit the setting table as described in section 4.3.2.
