System 182 Installation
3 - 31 ba76025e01 02/2012
Connecting the power
line
Fig. 3-26 Inserting the supply line.
5 Open the enclosure of the Universal Transmitter.
6 Screw a cable gland (pos. 1 in Fig. 3-26) with sealing ring (pos.
2) into the enclosure below the power supply connection.
7 Loosen the coupling ring (pos. 3).
8 Feed the power line through the cable gland into the enclosure.
When doing so bend the flexible divider (pos. 4) to the right.
1
3
2
L
N
