7.2 AquaForce MODBUS Communication Points (Continued)
Function Points # Point Range/ Modbus Units
Code Description Value Address
04 10 Drive #4 Current 0 to Span (in AquaForce 30010 A
User Setup Menu)
04 11 Drive #1 Power (KW) 0 to Span (in AquaForce 30011 KW
User Setup Menu)
04 12 Drive #2 Power (KW) 0 to Span (in AquaForce 30012 KW
User Setup Menu)
04 13 Drive #3 Power (KW) 0 to Span (in AquaForce 30013 KW
User Setup Menu)
04 14 Drive #4 Power (KW) 0 to Span (in AquaForce 30014 KW
User Setup Menu)
04 15 Speed % 0 to 100 30015 %
04 16 Lead Pump Number 1 to Pump # (in AquaForce 30016
User Setup Menu)
7.3 Quick Access Number Table
Screen Name Quick Access Screen Name Quick Access
Number Number
Sensor Setup (AI1) 1001 Pump Exercise 3031
Sensor Setup (AI2) 1002 Timed Auto Alt 3041
Number of Pumps 2001 Alternation Basis 3046
Pump Nameplate (Pump 1) 2002 PID 3051
Pump Nameplate (Pump 2) 2003 Reset Totals 3061
Pump Nameplate (Pump 3) 2004 Date, Time 3071
Pump Nameplate (Pump 4) 2005 Password 3081
Reset Pump Time 2008 Spare DO Setup 3092
PV Stage 3011 Spare AO Setup 3093
PV Destage 3012 Modbus 3103
Limit Power Stage 3016 Frict. Loss Comp. 3111
VFD Setup 3021 Save to Flash 3121
VFD Set Parameter 3022 Load from Flash 3122
VFD Read Parameter 3023 Load Defaults 3123
All Sys Sen Fail 3024 Display 3131
