Installation

< SELECTION: # >
8 = PASSWORD 0 = EXIT
9 = I/O SETUP
10 =COMMUNICATIONS
Press the

NEXT/( ) key to go to the next screen. The display now shows:

< SELECTION: # >
11 = FRIC. LOSS COMP.
12 = SAVE/LOAD
13 = DISPLAY 0 = EXIT
Pressing the

NEXT/( ) key again will take the screen back to the first screen.

Use the appropriate numeric key to select the desired menu, then press the

ENTER key. A detailed description

of each menu follows. For example, to select the

STAGE/DESTAGE menu, press the PV/1 key and then press

the

ENTER key.

4.10.3 Stage/ destage menu

Paths: Status Screens / Set up(3) / System(4) / StageDestage(1)

The first screen has been displayed below:
SELECTION: #
1 = PV STAGE 0=EXIT
2 = PV DESTAGE
6 = POWER LIMIT STAGE
By pressing the appropriate numeric key and

ENTER key, the setup can be completed.

See the following table for all

STAGE/DESTAGE menu items.

STAGE/DESTAGE SETUP MENU ITEMS

Menu Item

Variable

Default Range Field

Value

PV Stage

Stg Spd: ##%

0-100

The maximum speed at which the lead pump will

operate prior to starting a lag pump, %.

Stg Proof Timer: ### s

0-999

Proof timer prior to starting lag pump, seconds.

Stab Timer: ###s

0-999

Staging stabilization time, delay prior to calculating

destage value, seconds.

▲
