AQUAFORCE Installation, Operation, and Maintenance 31
Installation
4.10.33 Low discharge pressure
Paths: Status Screens / Set up(3) / AlrmEvt(6) / Low Discharge(2)
The Low Discharge Pressure menu is displayed below:
Low Dis Press: ##PSI
Low Dis Pr Tm: ##s
Alarm: $ Stop Pumps: $
OK? $ (Y/N)
See following table for all
LOW DISCHARGE PRESSURE menu items.
Low Discharge Pressure Menu Items
Menu Item Variable Default Range Field
Value
Low Low Dis Press: ### PSI 32 0-999
Discharge The pressure below which an alarm or
Pressure event will be set, in PSI
Low Dis PrTm: ###s 0 0-999
The proof timer prior to setting an alarm or event, in
seconds. A value of 0 disables this alarm or event.
Alarm: $ N Y/N
Set this value to “Y” to consider low discharge pressure
an alarm, or set it to “N” to consider it an event.
Stop Pumps: $ N Y/N
Set this value to “Y” to stop all pumps in the event of
a low pressure alarm or event. Set it to “N” to continue
operation normally during this alarm or event.
4.10.34 High discharge pressure
Paths: Status Screens / Set up(3) / AlrmEvt(6) / High Discharge(3)
The High Discharge Pressure menu is displayed below:
High Dis Press: ##
High Dis Pr Tm: ##s
OK? $ (Y/N)
See following table for all
HIGH DISCHARGE PRESSURE menu items.
High Discharge Pressure Menu Items
Menu Item Variable Default Range Field
Value
High High Dis Press: ### PSI 112 0-999
Discharge The pressure above which an alarm will be set, in PSI.
Pressure High Dis Pr Tm: ##s 20 0-999
The proof timer prior to setting an alarm, in seconds,
A value of 0 will disable this alarm.
4.10.35 Low suction pressure
Paths: Status Screens / Set up(3) / AlrmEvt(6) / Low Suction(4)
The Low Suction Pressure menu is displayed below:
Low Suct. Press: ##
Pr Tm: ##s Alarm: $
Auto Rst: $
Reset PSI: ## OK: $ (Y/N)
