AQUAFORCE Installation, Operation, and Maintenance 35
Operation
5. Operation
5.1 Normal Scrolling Operation
Other screens may be viewed by scrolling from the AquaForce Pump Controller screen shown below:
CONTROLLER
MM/DD/YY HH:MM:SS A/P
STAT1 STAT2 STAT3
The
STAT1 portion of the display indicates the current start/stop status of the system.
The STAT2 portion of the display indicates the current auto/manual mode of operation.
The following table indicates all possible options:
STAT2 Description Sections for Additional Information
AUTO Pump Controlled by Controller 5.2
MANUAL Pumps Controlled by User 5.4
The STAT3 portion of the display indicates the current alarm/event status. If NORMAL is displayed there are
no alarms. If ALARM or EVENT is displayed there are alarms/events that may prevent normal operation, refer
to Section 5.7 for additional information. In case of no flow shut down it displays *NFSD*.
Press the
NEXT/ ( ) key. The display now shows:
< PUMP STATUS >
P1: RDY
P2: N/A
P3: N/A P4: N/A
STAT1 STAT2 STAT3
Press the
NEXT/ ( ) key. The display now shows:
Dis = ###
SP = ###
Suc = ### Spd = ###%
STAT1 STAT2 STAT3
Press the
NEXT/ ( ) key. The display now shows:
< Power (KW) >
P1: ##
P2: ##
P3: N/A P4: N/A
STAT1 STAT2 STAT3
Press the
NEXT/ ( ) key. The display now shows:
< Current (A) >
P1: ##
P2: ##
P3: N/A P4: N/A
STAT1 STAT2 STAT3
Press the
NEXT/ ( ) key. The display now shows the following if the system is in MANUAL mode:
< >
Manual Speed: #%
STAT1 STAT2 STAT3
Press the
NEXT/ ( ) key. The display now returns back to the AquaForce Pump Controller screen.
Note:
When system is showing any of the above screens and if any key is not pressed for “Delay to Display status”
time, then the fourth line will start showing the system status.
▲
▲
▲
▲
▲
▲
