AQUAFORCE Installation, Operation, and Maintenance 16
Installation
REDIS MENU ITEMS
Menu Item Variable Default Range Field
Value
REDIS Active Sensor : ## 1 1-2
Enter the active discharge pressure sensor number
Drift Threshold: ##% 5 0-100
Pressure difference limit between the active and
redundant pressure sensor in %
Drift Pr Tm : ##s 0 0-999
Proof timer prior to give warning when exceed the
drift threshold limit, in seconds
To set up each field, press the NO/0 key and then press the ENTER key.
The ACTIVE SENSOR field will start blinking. Change the current value in Active Sensor field by pressing
desired numeric Keys and then press ENTER key to confirm.
Press ENTER key to accept the current DRIFT THRESHOLD value. To change the value in DRIFT
THRESHOLD field, press the desired Numeric Keys and then press ENTER to confirm.
Press
ENTER key to accept the current value of DRIFT PR TM. To change the value in DRIFT PR TM
field press the desired Numeric Keys and then press ENTER to confirm.
To accept the current values, press YES/7 key and then press ENTER key. The screen will go back to the
SENSOR SET UP menu displayed above.
Press the
NEXT/( ) key if additional sensors need to be set up. Repeat the above steps for all remaining
sensors.
Pressing
YES/7 key and then the ENTER key at the SENSOR SET UP screen will take the display back to
the MAIN SET UP screen.
4.10.1 Pump set up
Paths: Status Screens / Set up(3)
Press the SET UP/3 key at the Main Set Up menu screen. Then press the ENTER key.
The PUMP SET UP MENU will get displayed as shown below:
SELECTION: # 0= EXIT
1 = NUMBER OF PUMPS
2 = PUMP NAMEPLATE
3 = RESET PUMP TIME
To change the values in
NUMBER OF PUMPS field, press PV/1 key then press the ENTER key. The
following menu will get displayed:
TOTAL PUMPS: #
STANDBY PUMPS: #
OK $ (Y/N)
To set up each field, press the NO/0 key and ENTER key. Modify the values as desired using the appropriate
numeric key. The pump number is limited to the maximum number of pumps.
To accept the current values, press
YES/7 key and then press ENTER key.
The screen will go back to the PUMP SET UP MENU display.
To change the values in PUMP NAMEPLATE field, press SET PT/2 key then press the ENTER key. The
following menu will get displayed:
NAMEPLATE>
AMPS: ###.# HP: ###.#
VOLTS: ### Hz: ##
Spd: #### OK $ (Y/N)
▲
