36
SEq
NO.
LOCATION/
ITEM TO
INSPECT/CHECK/
SERVICE
PROCEDURE
NOT FULLY MISSION
CAPABLE IF...
10
Diopter Ring
of Optional
3X Magnifier
Rotate the diopter ring to make sure
the eyepiece is not too tight or too
loose. The range of the diopter is
covered with approximately 1 turn
of the ring.
Binding is not
moving freely or is
too loose, affecting
adjustment of the
diopter.
11
Body of
Optional
Red Dot System
Inspect for dirt, corrosion, cracks,
damage, or missing parts. Scratches
and gouges are admissible if
operation is not affected. Clean as
required.
Cracked or dam-
aged. Missing
parts.
12
Lenses of
Optional
Red Dot System
Inspect for dirt, fingerprint residue,
scratches, chips, or cracks. Clean as
required.
Scratches or chips
hinder vision.
Cracks are present.
13
Optional
Bracket PVS-14
Inspect for dirt, corrosion, damage,
and missing parts. Check for proper
operation. Clean as required.
Equipment is dam-
aged
Parts are missing.
OPERATIONAL CHECKS
NOTE:
Below the checks in daylight are described.
14
Switch Install the battery. Turn the switch
from “OFF” to “DAY” and change
the brightness of aiming mark using
the brightness adjustment buttons.
Look for the red aiming mark to
ensure the switch properly adjusts
the brightness of the aiming mark.
No Aiming mark is
visible.
The brightness of
the aiming mark
doesn’t change.
15
Boresight Perform boresight testing as shown
in Part 4.3.3.
Adjustment
mechanism is
inoperative.
POST-CHECK PROCEDURES
16
Turn the switch to “OFF”.
Remove the battery.
Return the equipment to the stor-
age/ carrying carton.
TABLE 4-1. CONTINUED
