If the AIM-PRO has been adjusted with an NVM or 3X Magnifier, you can save
these settings and use the Red Dot System’s adjustment screws.
To adjust the Red Dot System boresight in the daytime, do the following:
1. Mount the AIM-PRO to the weapon.
2. Locate a target at the fire adjustment range (100m).
3. Take aim at the center of the target using the weapon’s iron sight; secure
the weapon in the aiming rest.
4. Mount the Red Dot System to the AIM-PRO.
5. Unscrew the RDS’s protective screws.
6. Turn on the AIM-PRO in DAY mode. Adjust the brightness level of the aim-
ing mark.
7. Observing the target, take aim at the target by turning the windage and
elevation adjustment screws of Red Dot System until a red dot appears in
the center of your field of view. Shift the dot to the center of the target.
8. After you have completed the boresight adjustment procedure, replace
the protective screws.
3.3.3 AIM-PRO SHUT-DOWN
Shut down the AIM-PRO as follows:
1. Switch off the AIM-PRO.
2. Replace the cap on the collimator output prism.
3. Remove the AIM-PRO from the weapon.
4. Remove the NVM/ 3X Magnifier/ Red Dot System mounted on the AIM-
PRO.
5. Remove the battery.
CAUTION:
Do not store the equipment with the battery installed.
6. Return the equipment and its accessories to the storage case.
