TABLE 4-1. PREVENTIVE MAINTENANCE CHECKS AND SERVICES
SEq
NO.
LOCATION/
ITEM TO
INSPECT/CHECK/
SERVICE
PROCEDURE
NOT FULLY MISSION
CAPABLE IF...
BEFORE OPERATION CHECKS
1
Completeness Open storage/ carrying carton
and inventory items by comparing
them with the data specified in this
manual.
Items are missing.
2
Collimator
Body
Inspect for dirt, cracks, damage,
missing screws or missing prism
cap. Scratches and gouges are ad-
missible if operation is not affected.
Clean as required.
Items are cracked
or damaged. Some
parts are missing.
3 Prism Cap
Inspect for dirt, dust, cuts and tears.
Clean as required.
4
Battery
Compartment/
Cap/ Adapter
Inspect for corrosion, moisture,
corroded or defective contacts, for
damaged or missing o-ring.
Clean as required.
Contacts damaged
or corroded, o-ring
damaged or miss-
ing.
5 Turn-Pull
Switch
Check for operation (without the
battery installed).
Switch is inopera-
tive.
6 Output Prism
Inspect for dirt, scratches, chips, or
cracks. Clean as required.
Scratches, chips or
cracks are present.
7
Mount Inspect for damage or corrosion,
and for missing parts. Check for
proper operation.
Damaged. Some
parts missing.
Clamping devices
are inoperative.
8
Body of
Optional
3X Magnifier
Inspect for dirt, corrosion, cracks,
damage, or parts missing. Scratches
and gouges are admissible if
operation is not affected. Clean as
required.
Cracked or dam-
aged. Missing
parts.
9
Lenses of
Optional
3X Magnifier
Inspect for dirt, fingerprint residue,
scratches, chips, or cracks. Clean as
required.
Scratches or chips
hinder vision.
Cracks are present.
