GE
Data Sheet
KBVW006A0B Series Sixteenth-Brick Power Modules
36–75Vdc Input; 12.0Vdc Output; 6A Output Current
July 9, 2013 ©2012 General Electric Company. All rights reserved. Page 3
Electrical Specifications (continued)
Parameter Device Symbol Min Typ Max Unit
Nominal Output Voltage Set-point
V
IN
= 48V I
O
=I
O, max
, T
A
=25°C) All V
O, set
11.67 12.0 12.25 V
dc
Output Voltage
All V
O
11.64  12.36 V
dc
(Over all operating input voltage, resistive load, and
temperature conditions until end of life)
Output Regulation
Line (V
IN
=V
IN, min
to V
IN, max
) All   ±0.2 % V
O, set
Load (I
O
=I
O, min
to I
O, max
) All   ±0.2 % V
O, set
Temperature (T
ref
=T
A, min
to T
A, max
) All   ±1.0 % V
O, set
Output Ripple and Noise
(Co=1uF,ceramic+10uF,tantalum,V
IN
=V
IN, min
to V
IN, max
, I
O
= I
O, max
,
T
A
=T
A, min
to T
A, max
)
RMS (5Hz to 20MHz bandwidth) All  40  mV
rms
Peak-to-Peak (5Hz to 20MHz bandwidth) All  120  mV
pk-pk
External Capacitance 1 All C
O, max
0  2,000 μF
Output Current All I
o
0  6 A
dc
Output Current Limit Inception (Hiccup Mode )
All I
O, lim 105 120 140 % I o
(V
O
= 90% of V
O, set
)
Output Short-Circuit Current
All I
O, s/c
2.5 A
rms (V
O
≤250mV) ( Hiccup Mode )
Efficiency
V
IN
=48V, T
A
=25°C, I
O
=I
O, max ,
V
O
= V
O,set
All η 91.0 %
Switching Frequency All f
sw
350 kHz
Dynamic Load Response
(Co=1uF,ceramic+10uF,tantalum,dI
o
/dt=0.1A/s; V
IN
= 48V;
T
A
=25°C)
Load Change from Io= 50% to 75% or 25% to 50% of I
o,max
Peak Deviation All V
pk
 360  mV
Settling Time (Vo<10% peak deviation) All t
s
 200  s
1. See Note 2 under Feature Specifications.
Isolation Specifications
Parameter Device Symbol Min Typ Max Unit
Isolation Capacitance All C
iso
 1000  pF
Isolation Resistance All R
iso
10   MΩ
I/O Isolation Voltage (100% factory Hi-pot tested) All All   2250 V
dc
General Specifications
Parameter Device Symbol Min Typ Max Unit
Calculated Reliability based upon Telcordia SR-332 Issue 3:
Method
I Case 3 (I
O
=80%I
O, max
, T
A
=40°C, airflow = 200 lfm, 90%
confidence)
All FIT 89.8 10 9 /Hours
All MTBF 11,133,281 Hours
Weight (Open Frame) All 13 (0.46) g (oz.)
Weight (with Heatplate) All 21 (0.74) g (oz)
