Data Sheet
KBVW006A0B Series Sixteenth-Brick Power Modules
36–75Vdc Input; 12.0Vdc Output; 6A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243
, or +1 972 244
9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.878067-280
India:
+91.80.28411633
www.ge.com/powerelectronics
July 9, 2013
©2012 General Electric Company. All rights reserved.
Version 1.6
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Product Codes
Input Voltage
Output
Voltage
Output
Current
On/Off Logic
Connector
Type
Comcodes
KBVW006A0B41Z
48V (36-75Vdc)
12.0V
6A
Negative
Through hole
CC109170544
KBVW006A0B641Z
48V (36-75Vdc)
12.0V
6A
Negative
Through hole
150024448
KBVW006A0B841Z
48V (36-75Vdc)
12.0V
6A
Negative
Through hole
150024014
KBVW006A0B41-HZ
48V (36-75Vdc)
12.0V
6A
Negative Through
hole 150021662
KBVW006A0B41-SRZ
48V (36-75Vdc)
12.0V
6A
Negative Surface
mount 150021663
Table 2. Device Coding Scheme and Options
