NH033x-L and NH050x-L Series Power Modules:

Data Sheet

5 Vdc Input; 1.2 Vdc to 3.3 Vdc Output; 10 A and 15

March 2010

April 2008

FDS01-070EPS (Replaces FDS01-069EPS)

Ordering Information

Please contact your Lineage Power Account Manager or Field Application Engineer for pricing and availability.

Table 3. Device Codes

Table 4. Device Options

Input Voltage

Output Voltage

Output Power

Device Code

Comcode

5 V

1.5 V

15 W

NH033M-L

107993685

5 V

1.8 V

18 W

NH033S1R8-L

107940306

5 V

2.5 V

25 W

NH033G-L

107917122

5 V

3.3 V

33 W

NH033F-L

107859928

5 V

1.5 V

22.5 W

NH050M-L

107993693

5 V

1.8 V

27 W

NH050S1R8-L

107940314

5 V

2.5 V

37.5 W

NH050G-L

107917130

5 V

3.3 V

50 W

NH050F-L

107917148

Option

Suffix

Tight tolerance output

Short pins: 2.79 mm ± 0.25 mm

(0.110 in. ± 0.010 in.)
