NH033x-L and NH050x-L Series Power Modules: Data Sheet
5 Vdc Input; 1.2 Vdc to 3.3 Vdc Output; 10 A and 15 A March 2010
18 Lineage Power
Outline Diagram
Dimensions are in millimeters and (inches).
Tolerances: x.x mm ± 0.5 mm (x.xx in. ± 0.02 in.), x.xx mm ± 0.25 mm (x.xxx in. ± 0.010 in.).
8-1176(C).b
* Label includes product designation and date code.
5.84
(0.230)
25.4
(1.00)
8.6
(0.34)
MAX
SQUARE PIN
0.64 x 0.64
(0.025 x 0.025)
45.7 (1.80)
48.3 (1.90)
43.2 (1.70)
40.6 (1.60)
2.54 (0.100)
1.8
(0.07)
7.62
(0.300)
5.08
(0.200)
20.3
(0.80 2.54
(0.100)
17.3
(0.68)
17.8
(0.70)
69.9 (2.75)
25.4
(1.00)
LABEL*
Bottom View
Side View
Top View
