3.1.1 Dimensions and weights
LP 33U Series 10 & 20 kVA - DIMENSIONS
UPS model
Dimensions
(W x D x H)
LP 33U Series / 10 kVA
22.29 x 30.71 x 51.58”
566 x 780 x 1310 mm
LP 33U Series / 20 kVA
22.29 x 30.71 x 51.58”
566 x 780 x 1310 mm
LP 33U Series 10 & 20 kVA - WEIGHT
UPS without battery UPS with battery
UPS
model
UPS
UPS floor
loading
UPS with
standard
shipping
UPS with
battery
Floor
loading
UPS with
standard
shipping
LP 33U
Series
10 kVA
397 lbs
180 Kg
84 lbs/sq.ft
408 Kg/m 2
430 lbs
195 Kg
*640 - °871 lbs
*290 - °395 Kg
*135 - °184 lbs/sq.ft
*657 - °895 Kg/m 2
*673 - °905lbs
*305 - °410Kg
LP 33U
Series
20 kVA
430 lbs
195 Kg
91 lbs/sq.ft
442 Kg/m
2
464 lbs
210 Kg
410 Kg (24 Ah)
905 lbs (24 Ah)
191 lbs/sq.ft (24 Ah)
929 Kg/m
2 (24 Ah)
938 lbs (24 Ah)
425 Kg (24 Ah)
(*) Battery 12 Ah (°) Battery 24 Ah (2 x 12 Ah)
LP 33U Series 10 & 20 kVA - BATTERY TABLE
UPS
model
Battery
capacity
Autonomy
time
Cabinet
12 Ah 9 min. LP 33U
Series
10 kVA 24 Ah (2 x 12 Ah) 26 min.
Mounted inside the UPS cabinet (see Weight table)
LP 33U
Series
20 kVA
24 Ah (2 x 12 Ah) 9 min. Mounted inside the UPS cabinet (see Weight table)
Fig. 3.1.1-1 Dimensions LP 33U Series
Battery autonomy time at 100% load and PF=0.8 lag., only with High Rate Battery
NOTE !
The weight of each single piece is marked outside the package!
