Data Sheet
6A Digital PicoDLynx TM : Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.45Vdc to 5.5Vdc output; 6A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.74423-206
India:
+91.80.28411633
www.ge.com/powerelectronics
April 29, 2013 ©2013 General Electric Company. All rights reserved. Version 1.09
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 9. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Sequencing Comcodes
PDT006A0X3-SRZ 3 – 14.4Vdc 0.45 – 5.5Vdc 6A Negative Yes CC109159604
PDT006A0X3-SRDZ 3 – 14.4Vdc 0.45 – 5.5Vdc 6A Negative Yes 150021751
PDT006A0X43-SRZ 3 – 14.4Vdc 0.45 – 5.5Vdc 6A Positive Yes CC109159612
-Z refers to RoHS compliant parts
Table 10. Coding Scheme
GE Digital Non-Isolated DC-DC products use technology licensed from Power-One, protected by US patents: US20040246754, US2004090219A1, US2004093533A1, US2004123164A1,
US2004123167A1, US2004178780A1, US2004179382A1, US20050200344, US20050223252, US2005289373A1, US20060061214, US2006015616A1, US20060174145, US20070226526,
US20070234095, US20070240000, US20080052551, US20080072080, US20080186006, US6741099, US6788036, US6936999, US6949916, US7000125, US7049798, US7068021, US7080265,
US7249267, US7266709, US7315156, US7372682,
US7373527, US7394445, US7456617, US7459892, US7493504, US7526660.
Outside the US the Power-One licensed technology is protected by patents: AU3287379AA, AU3287437AA, AU3290643AA, AU3291357AA, CN10371856C, CN1045261OC, CN10458656C,
CN10459360C, CN10465848C, CN11069332A, CN11124619A, CN11346682A, CN1685299A, CN1685459A, CN1685582A, CN1685583A, CN1698023A, CN1802619A, EP1561156A1, EP1561268A2,
EP1576710A1, EP1576711A1, EP1604254A4, EP1604264A4, EP1714369A2, EP1745536A4, EP1769382A4, EP1899789A2, EP1984801A2, W004044718A1, W004045042A3, W004045042C1,
W004062061 A1, W004062062A1, W004070780A3, W004084390A3, W004084391A3, W005079227A3, W005081771A3, W006019569A3, W02007001584A3, W02007094935A3
Package
Identifier
Family Sequencing
Option
Output
current
Output
voltage
On/Off
logic
Remote
Sense Options
ROHS Compliance
P D T 006A0 X 4 3 -SR -D Z
P=Pico
U=Micro
M=Mega
G=Giga
D=Dlynx
Digital
V =
DLynx
Analog.
T=with EZ
Sequence
X=without
sequencing
6A X =
programma
ble output
4 =
positive
No entry
=
negative
3 =
Remote
Sense
S =
Surface
Mount
R =
Tape &
Reel
D = 105°C
operating
ambient,
40G
operating
shock as per
MIL Std 810F
Z = ROHS6
