6A Digital PicoDLynx TM : Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.45Vdc to 5.5Vdc output; 6A Output Current
April 29, 2013 ©2013 General Electric Company. All rights reserved. Page 26
Hex
Code
Command Brief Description
Non-Volatile
Memory Storage
22 VOUT_TRIM
Apply a fixed offset voltage to the output voltage command value
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function High Byte
Default Value 0 0 0 0 0 0 0 0
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function Low Byte
Default Value 0 0 0 0 0 0 0 0
YES
25 VOUT_MARGIN_HIGH
Sets the target voltage for margining the output high
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r/w r/w r/w r/w r/w r/w r/w
Function High Byte
Default Value 0 0 0 0 0 1 0 1
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function Low Byte
Default Value 0 1 0 0 0 1 1 1
YES
26 VOUT_MARGIN_LOW
Sets the target voltage for margining the output low
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r/w r/w r/w r/w r/w r/w r/w
Function High Byte
Default Value 0 0 0 0 0 1 0 0
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function Low Byte
Default Value 0 1 0 1 0 0 0 1
YES
29 VOUT_SCALE_LOOP
Sets the scaling of the output voltage – equal to the feedback resistor divider
ratio
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r r/w r/w
Function Exponent Mantissa
Default Value 1 0 1 1 1 0 0 1
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function Mantissa
Default Value 0 0 0 0 0 0 0 0
YES
35 VIN_ON
Sets the value of input voltage at which the module turns on
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r r r
Function Exponent Mantissa
Default Value 1 1 1 1 0 0 0 0
Bit Position 7 6 5 4 3 2 1 0
Access r r/w r/w r/w r/w r/w r/w r/w
Function Mantissa
Default Value 0 0 0 0 1 0 1 1
YES
