GE
Data Sheet
6A Digital PicoDLynx TM : Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.45Vdc to 5.5Vdc output; 6A Output Current
April 29, 2013 ©2013 General Electric Company. All rights reserved. Page 27
Table 6 (continued)
Hex
Code
Command Brief Description
Non-Volatile
Memory Storage
36 VIN_OFF
Sets the value of input voltage at which the module turns off
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r r r
Function Exponent Mantissa
Default Value 1 1 1 1 0 0 0 0
Bit Position 7 6 5 4 3 2 1 0
Access r r/w r/w r/w r/w r/w r/w r/w
Function Mantissa
Default Value 0 0 0 0 1 0 1 0
YES
38 IOUT_CAL_GAIN
Returns the value of the gain correction term used to correct the measured
output current
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r r r/w
Function Exponent Mantissa
Default Value 1 0 0 0 1 0 0 V
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function Mantissa
Default Value V: Variable based on factory calibration
YES
39 IOUT_CAL_OFFSET
Returns the value of the offset correction term used to correct the measured
output current
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r r r r r/w r r
Function Exponent Mantissa
Default Value 1 1 1 0 0 V 0 0
Bit Position 7 6 5 4 3 2 1 0
Access r r r/w r/w r/w r/w r/w r/w
Function Mantissa
Default Value 0 0 V: Variable based on factory calibration
YES
40 VOUT_OV_FAULT_LIMIT
Sets the voltage level for an output overvoltage fault
Format Linear, two’s complement binary
Bit Position 7 6 5 4 3 2 1 0
Access r r/w r/w r/w r/w r/w r/w r/w
Function High Byte
Default Value 0 0 0 0 0 1 0 1
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r/w r/w r/w
Function Low Byte
Default Value 0 0 0 0 1 0 1 0
YES
41 VOUT_OV_FAULT_RESPONSE
Instructs the module on what action to take in response to a output overvoltage
fault
Format Unsigned Binary
Bit Position 7 6 5 4 3 2 1 0
Access r/w r/w r/w r/w r/w r r r
Function
RSP
[1]
RSP
[0]
RS[2] RS[1] RS[0] X X X
Default Value 1 1 1 1 1 1 0 0
YES
