Power Management Control System
Chapter 1 – Introduction
8
IED Name IED Name IED Name IED Name Function Communications Protocol (Modbus Speed)
RS-485 Repeater Communications Modbus RTU (19.2 Kbaud)
369 Motor Management Relay Metering/Control Modbus RTU (19.2 Kbaud)
EPM 7500 Electronic Power Meter Protection/Control Modbus RTU (19.2 Kbaud)
EPM 7600 Electronic Power Meter Protection/Control Modbus RTU (19.2 Kbaud)
Motor Manager II (MMII) Protection/Control Modbus RTU (19.2 Kbaud)
EPM7430D/EPM7450D (Futura) Protection/Control Modbus RTU ( 9600 baud)
Spectra Electronic Control Module Protection commnet (requires Modbus Concentrator)
Spectra MVT for GEK Frame MCCB Metering/Protection commnet (requires Modbus Concentrator)
SR469 Motor Management Relay Protection/Control Modbus RTU (19.2 Kbaud on 1 or 2 ports)
SR489 Generator Management Relay Protection/Control Modbus RTU (19.2 Kbaud on 1 or 2 ports)
SR745 Transformer Management Relay Protection/Control Modbus RTU (19.2 Kbaud on 1 or 2 ports)
SR750 Feeder Management Relay Protection/Control Modbus RTU (19.2 Kbaud on 1 or 2 ports)
SR760 Feeder Management Relay Protection/Control Modbus RTU (19.2 Kbaud on 1 or 2 ports)
POWER LEADER MDP Overcurrent Relay Protection Modbus (19.2 Kbaud) or commnet
(commnet requires Modbus Concentrator)
POWER LEADER Modbus Monitor Monitoring Modbus RTU (19.2 Kbaud on 1 or 2 ports)
POWER LEADER Meter Metering commnet (requires Modbus Concentrator)
Table 1. IEDs supported by PMCS. 2
2 The POWER LEADER Ethernet Gateway is not listed in Table 1. The Ethernet Gateway is an alternate host for the RS-485 networks used when the
PMCS resides on the Ethernet level.
