GE Industrial Solutions AF-300 G11 User Manual

Page 120

background image

10-3

Data subject to change without notice 7/07. © 2007 GE Drives

Catalog No.

Rating

Drive HP & Quantity per drive

1/2

1

2

3

5

7.5

10

15

20

25

30

AF-300 G11 460 VAC, 30 Hp and Below

Main Control Card
G11CPCBB1

1

1

1

1

1

1

1

1

1

1

1

Gate Driver & Power Supply Card
G11PPCBG4004

1

G11PPCBG4008

1

G11PPCBG4015

1

G11PPCBG4022

1

G11PPCBG4037

1

G11PPCBG4055

1

G11PPCBG4075

1

G11PPCBG4110

1

G11PPCBG4150

1

G11PPCBG4185

1

G11PPCBG4220

1

KEYPAD PANEL (Only one type per drive)
TPAG11S

NEMA1

1

1

1

1

1

1

1

1

1

1

1

TPAG11S4

NEMA Type4

1

1

1

1

1

1

1

1

1

1

1

DC CAPACITOR

*

*

G11CAP04

PCB

1

G11CAP05

PCB

1

G11CAP06

PCB

1

G11CAP07

1500µF

2

G11CAP08

2000µF

2

G11CAP09

2700µF

2

G11CAP10

3900µF

2

G11CAP11

4700µF

2

G11CAP12

5400µF

2

* Located on Gate drive & Power supply Card

FAN

G11FAN01

1

1

1

G11FAN02

1

1

2

2

2

2

POWER MODULE

*

*

PS12046

15A 1200V

1

1

PS12047

25A 1200V

1

6MBP50RS120

50A 1200V

1

1

6MBP75RS120

75A 1200V

1

1

6MBP100RS120

100A 1200V

1

1

* Located on Gate drive & Power supply Card

RECTIFIER MODULE

*

*

*

*

*

PVC75-16

75A 1600V

1

1

CLK70AA160

70A 1600V

1

1

CLK100AA160

100A 1600V

1

1

* Located on Gate drive & Power supply Card

CHARGE RESISTOR

*

*

*

*

*

30W200

30W 20WJ

1

1

80W100

80W 10WJ

1

1

1

1

* Located on Gate drive & Power supply Card

FRONT COVER
G11UPCG008

1

1

G11UPCG040

1

1

1

G11UPCG075

1

1

G11UPCG220

1

1

1

1

INTERNAL DB RESISTOR
G11DBR0044

720W 30W

1

G11DBR0084

470W 40W

1

G11DBR0374

200W 80W

1

1

1

G11DBR0754

100W 90W

1

1
