Data subject to change without notice 7/07. © 2007 GE Drives
HP
Rating
NEMA
Enclosure
Rated Output
Current (A)
Overload
(150% 1min.)
AF-300G11
Model No.
Catalog
No.
Dimensions
H x W x D (inches)
Weight
(lbs)
230VAC, 3 phase, 50/60Hz Input, Open with NEMA 12 Heatsink
40 Open 115 173 6KG1123040X8## --- 21.7 x 13.4 x 10.0 64
50 Open 145 218 6KG1123050X8## --- 24.2 x 14.8 x 10.6 79
60 Open 180 270 6KG1123060X8## --- 29.1 x 14.8 x 10.6 97
75 Open 215 323 6KG1123075X8## --- 29.1 x 14.8 x 10.6 101
100 Open 283 425 6KG1123100X8## --- 29.5 x 20.9 x 11.2 154
125 Open 346 519 6KG1123125X8## --- 34.6 x 26.8 x 14.2 253
460VAC, 3 phase, 50/60Hz Input, NEMA 1
0.5 1 1.5 2.3 6KG1143F50X1## D6519 10.24 x 4.33 x 5.12 4.8
1 1 2.5 3.8 6KG1143001X1## D6520 10.24 x 4.33 x 5.71 5.5
2 1 3.7 5.6 6KG1143002X1## D6521 10.24 x 5.91 x 5.71 8.4
3 1 5.5 8.3 6KG1143003X1## D6522 10.24 x 5.91 x 5.71 8.4
5 1 9 14 6KG1143005X1## D6523 10.24 x 5.91 x 5.71 8.4
7.5 1 13 20 6KG1143007X1## D6524 10.24 x 8.66 x 7.68 14.3
10 1 18 27 6KG1143010X1## D6525 10.24 x 8.66 x 7.68 14.3
15 1 24 36 6KG1143015X1## D6526 15.75 x 9.84 x 7.68 22.0
20 1 30 45 6KG1143020X1## D6527 15.75 x 9.84 x 7.68 22.0
25 1 39 59 6KG1143025X1## D6528 15.75 x 9.84 x 7.68 23.1
30 1 45 68 6KG1143030X1## D6529 15.75 x 9.84 x 7.68 23.1
40 1 60 90 6KG1143040X1## D6531 29.7 x 13.5 x 10.0 70
50 1 75 113 6KG1143050X1## D6532 29.7 x 14.9 x 10.6 82
60 1 91 137 6KG1143060X1## D6533 34.6 x 14.9 x 10.6 95
75 1 112 168 6KG1143075X1## D6534 34.6 x 14.9 x 10.6 97
100 1 150 225 6KG1143100X1## D6535 38.0 x 14.9 x 10.6 115
125 1 176 264 6KG1143125X1## D6536 38.0 x 21.0 x 12.4 174
150 1 210 315 6KG1143150X1## D6537 38.0 x 21.0 x 12.4 245
200 1 253 380 6KG1143200X1## D6538 53.1 x 21.0 x 14.2 245
250 1 304 456 6KG1143250X1## D6539 53.1 x 21.0 x 14.2 245
300 1 377 566 6KG1143300X1## D6540 55.1 x 26.9 x 14.2 337
350 1 415 623 6KG1143350X1## D6541 55.1 x 26.9 x 14.2 337
400 1 520 780 6KG1143400X1## D6542 57.1 x 26.8 x 17.7 562
450 1 585 878 6KG1143450X1## D6543 57.1 x 26.8 x 17.7 562
500 1 650 975 6KG1143500X1## D6544 57.1 x 34.6 x 17.7 804
600 1 740 1110 6KG1143600X1## D6545 57.1 x 34.6 x 17.1 804
460VAC, 3 phase, 50/60Hz Input, NEMA 4
0.5 4 1.5 2.3 6KG1143F50X4## D6569 10.24 x 4.33 x 5.12 4.8
1 4 2.5 3.8 6KG1143001X4## D6570 10.24 x 4.33 x 5.71 5.5
2 4 3.7 5.6 6KG1143002X4## D6571 10.24 x 5.91 x 5.71 8.4
3 4 5.5 8.3 6KG1143003X4## D6572 10.24 x 5.91 x 5.71 8.4
5 4 9 14 6KG1143005X4## D6573 10.24 x 5.91 x 5.71 8.4
7.5 4 13 20 6KG1143007X4## D6574 10.24 x 8.66 x 7.68 14.3
10 4 18 27 6KG1143010X4## D6575 10.24 x 8.66 x 7.68 14.3
460VAC, 3 phase, 50/60Hz Input, NEMA 12
15 12 24 36 6KG1143015X2## D6576 15.75 x 9.84 x 7.68 22.0
20 12 30 45 6KG1143020X2## D6577 15.75 x 9.84 x 7.68 22.0
25 12 39 59 6KG1143025X2## D6578 15.75 x 9.84 x 7.68 23.1
30 12 45 68 6KG1143030X2## D6579 15.75 x 9.84 x 7.68 23.1
## Indicates product revision.
Note: Horsepower rating is shown for 230V and 460V nominal systems, 1800 RPM motors.
When applying at lower voltage and lower speed AC motors, select the drive by rated current and not Hp rating.
AF-300 G11 Dimensions & Weights
