GE Industrial Solutions GPS 4812_24 - Manual (Page 69)

Galaxy Power System 4812/24
Issue 9 Preliminary Januray 2008 Specifications 9 - 7
DC Distribution Panels
Table 9-E: Battery Connection Panels
Protector Type
1
Positions
2
Panel
3
Figure H569-436 ED83141-31
3-100A plug-in fuse holders or CB 14 G40, G50 G11 7-1
3-100A plug-in fuse holders or CB 22 G41, G51 G12 7-2
125-600A CB 3 G42 G2 7-3
125-600A CB 6 G43 G1 7-4
125-600A CB 5 G44 G5 7-5
3-150A plug-in bullet CB 10 G46 G15 7-6
3-70A TPS fuse 10 G52 G53 7-7
100-600A TPL-C fuse 2 G53 G55 7-8
1-63A DIN CB 14 G60 G71 7-9
80-125A DIN CB 10 G61 G71 7-9
1-32A DIN fuse 14 G65 G71 7-9
1-50A DIN fuse 10 G66 G71 7-9
4-160A DIN NH00 fuse 8 G67 G22 7-10
32-400A DIN NH2 fuse 2 G68 G21 7-11
1. NH3 Fuse Holders accept DIN Fuses 315 to 630A
2. US Fuse Holders accept TPL-CZ fuses < 600A
3. 400A Circuit Breaker uses 2 positions
4. Off-Line Equalize panels use ES671 Off-line Equalize Converter to provide battery equalize voltage
