Galaxy Power System 4812/24
Issue 9 Januray 2008
Battery Connection Panels 6 - 1
6
Battery Connection Panels
Overview
Function
Batteries are connected to the GPS 4812/24 cabinets on battery
connection panels located in the cabinet directly below or behind the ac
input panel. All panels include the battery shunts and an alarm card that
communicates with the controller to provide battery current and status
information. As options, the panels may include fuses or low voltage
battery disconnect/reconnect (LVBD/R) contactors. When equipped
with contactors, a contactor control card provides local/manual control
of the contactors.
Note: If no battery panel is needed (for full height supplemental cabinets
only), H569-436 G33F is selected as a placeholder in the order.
Illustrations
The battery connection panels are shown in Figures 6-1 through 6-10.
Note: Battery connection panels are blue; dc distribution panels are
white.
