Data Sheet
PIM400 Series; ATCA Board Power Input Modules
-36 to -75 Vdc; 400W/10A
June 20, 2013 ©2013 General Electric Company. All rights reserved. Page 6
Digital Interface Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature conditions. See
Feature Descriptions for additional information.
Parameter Conditions Symbol Min Typ Max Unit
Digital Signal Interface Characteristics
Clock frequency range
f
CLK
100 400 kHz
Measurement Tolerance
Feed Voltage A/B (-48V_AF & -48V_BF) +/-3 %
Holdup Voltage (V_HLDP) +/-3 %
-48V_OUT current (-48V_IOUT) % of Io,max +/-3 %
Module Temperature (TEMP) +/-3 0 C
General Specifications
Parameter Device Min Typ Max Unit
Calculated MTBF (P
O
=0.8P
O, RATED
, 48V
IN
, T
A
=40°C, Airflow=300LFM)
Telecordia Issue 2 Method 1 Case 3
All 2,308,563 Hours
Weight  28.3 (1.0)  g (oz.)
