GE
Data Sheet
PIM400 Series; ATCA Board Power Input Modules
-36 to -75 Vdc; 400W/10A
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.878067-280
India:
+91.80.28411633
www.ge.com/powerelectronics
June 20, 2013 ©2012 General Electric Company. All rights reserved. Version 1.02
Ordering Information
Please contact GE’s Sales Representative for pricing, availability and optional features.
Table 1. Device Code
Input Voltage
Current
Rating
Auxiliary
Output #1
Auxiliary
Output #2
Options Product codes Comcodes
-36 to -75 Vdc 10A 3.3V/3.6A
5.0V/0.15A -
PIM400Z 150019196
-36 to -75 Vdc 10A 3.3V/3.6A 5.0V/0.15A I 2 C Digital Interface PIM400KZ 150019197
-36 to -75 Vdc 10A 3.3V/3.6A 5.0V/0.15A
I 2 C Digital Interface & Short
pins (3.68mm)
PIM400K6Z 150033384
Table 2. Device Options
Option Device Code Suffix
Short pins: 3.68mm ± 0.25mm (0.145 in. ± 0.010 in.)
6
Short pins: 2.79mm ± 0.25mm (0.110 in. ± 0.010 in.)
8
I 2 C Digital Interface K
Table 3. Related Products
Description Product Code Comcode
PIM400 Evaluation Board EVAL_PIM400 150030502
QBDW033A0B Series Power Modules; DC-DC Converters
36-75V
dc
Input; 8.1-13.2V
dc
Output; 33A Output Current
QBDW033A0B41Z CC109159307
QBVW033A0B Series Power Modules; DC-DC Converters
36-75V
dc
Input; 8.1-13.2V
dc
Output; 33A Output Current
QBVW033A0B41Z CC109165247
