To better understand the ECO Mode programming modes, some typical examples are shown:
Example 1:
For continuous ECO Mode set the ECO Mode START times to 00:00 and the ECO Mode STOP times to
23:59 for all weekdays, but almost 1 day must have 1 minute of VFI programming: i.e. d2 - Sunday
00:00 to 23:58).
Weekday d1
- Saturday
d2
- Sunday
d3
- Monday
d4
- Tuesday
d5
- Wednesday
d6
- Thursday
d7
- Friday
ECO Mode START 00:00 00:00 00:00 00:00 00:00 00:00 00:00
ECO Mode STOP 23:59 23:58 23:59 23:59 23:59 23:59 23:59
Example 2:
ECO Mode STOP before ECO Mode START.
ECO Mode START 18:00, ECO Mode STOP 06:00 for weekday d4 - Tuesday.
Means that on d4 - Tuesday the ECO Mode is active between 00:00 and 06:00 and between 18:00 and
23:59.
Weekday d1
- Saturday
d2
- Sunday
d3
- Monday
d4
- Tuesday
d5
- Wednesday
d6
- Thursday
d7
- Friday
ECO Mode START 00:00 00:00 00:00 18:00 00:00 00:00 00:00
ECO Mode STOP 23:59 23:59 23:59 06:00 23:59 23:59 23:59
Example 3:
ECO Mode during the night and week-end.
If the ECO Mode must be enabled all nights (d3 - Monday to d7 - Friday) between 18:00 in the evening
and 06:00 of the following morning and during all Saturday (d1) and Sunday (d2), the corresponding
parameters are:
Weekday d1
- Saturday
d2
- Sunday
d3
- Monday
d4
- Tuesday
d5
- Wednesday
d6
- Thursday
d7
- Friday
ECO Mode START 00:00 00:00 18:00 18:00 18:00 18:00 18:00
ECO Mode STOP 23:59 23:59 06:00 06:00 06:00 06:00 06:00
Example 4:
If the ECO Mode must be enabled on Monday (d3) and Tuesday (d4) between 18:00 in the evening and
06:00 of the following morning, on Friday (d7) between 12:00 and 13:00, during all Saturday (d1) and on
Sunday (d2) until 20:00, the corresponding parameters are.
Weekday d1
- Saturday
d2
- Sunday
d3
- Monday
d4
- Tuesday
d5
- Wednesday
d6
- Thursday
d7
- Friday
ECO Mode START 00:00 00:00 18:00 18:00 00:00 00:00 12:00
ECO Mode STOP 23:59 20:00 23:59 06:00 06:00 00:00 13:00
ECO Mode START
ECO Mode STOP
In dark color are displayed the times with ECO Mode operation.
The arrows indicate the conditions given by the ECO Mode START and ECO Mode STOP times introduced
with the parameters.
Note that on day d6 - Thursday the interval has length 0 (zero), therefore the ECO Mode is not enabled
on this day.
