Mains supply 3 x 380-480 V
Model number
AF-600 FP 650 750 900 1000 1200 1350
AF-650 GP 600 650 750 900 1000 1200
Light duty (LD) current ratings (110 %):
Output current Nominal [A] (380-440 V) 880 990 1120 1260 1460 1720
MAX (60 sec) [A] (380-440
V)
968 1089 1232 1386 1606 1892
Nominal [A] (441-500 V) 780 890 1050 1160 1380 1530
MAX (60 sec) [A] (441-500
V)
858 979 1155 1276 1518 1683
Output Nominal [kVA] (400 V) 610 686 776 873 1012 1192
Nominal [kVA] (460 V) 621 709 837 924 1100 1219
Nominal [kVA] (500 V) 675 771 909 1005 1195 1325
Typical shaft output [kW] (400 V) 500 560 630 710 800 1000
[HP] (460 V) 650 750 900 1000 1200 1350
[kW] (500 V) 560 630 710 800 1000 1100
Heavy duty (HD) torque (160 %):
Output current Nominal [A] (380-440 V) 800 880 990 1120 1260 1460
MAX (60 sec) [A] (380-440
V)
1200 1320 1485 1680 1890 2190
Nominal [A] (441-500 V) 730 780 890 1050 1160 1380
MAX (60 sec) [A] (441-500
V)
1095 1170 1335 1575 1740 2070
Output Nominal [kVA] (400 V) 554 610 686 776 873 1012
Nominal [kVA] (460 V) 582 621 709 837 924 1100
Nominal [kVA] (500 V) 632 675 771 909 1005 1195
Typical shaft output [kW] (400 V) 450 500 560 630 710 800
[HP] (460 V) 600 650 750 900 1000 1200
[kW] (500 V) 530 560 630 710 800 1000
400V Power loss Light
duty (LD) [W]
10161 11822 12514 14671 17294 19280
400V Power loss Heavy
duty (HD) [W]
9031 10145 10649 12492 14244 15467
460V Power loss Light
duty (LD)[W]
8877 10424 11595 13215 16228 16625
460V Power loss Heavy
duty (HD) [W]
8211 8861 9416 11580 13003 14554
Limits and Ranges
Overcurrent Warning A rms Out 1866 1786 2342 2600 2679 3514
Overcurrent Alarm (1.5
sec delay)
A rms Out 1866 1786 2342 2600 2679 3514
Earth (Ground) Fault
Alarm
A rms Out 400 440 495 560 630 730
Short Curcuit Alarm A rms Out 2256 2256 2974 3308 3384 4462
Heatsink Over Temper-
ature ° C 95 95 95 95 95 95
Heatsink Under Tem-
perature Warning ° C 0 0 0 0 0 0
Power Card Ambient
Over Temperature ° C 68 68 68 68 68 68
Power Card Ambient
Under Temperature ° C -20 -20 -20 -20 -20 -20
Mains Phase Warning (5
sec delay)
DC Bus Ripple Vpeak 30 30 30 30 30 30
Mains Phase Alarm (25
sec delay)
DC Bus Ripple Vpeak 30 30 30 30 30 30
Table 1.5: Mains supply 3 x 380-480 V
