Page 7: High power service manual for unit sizes 6x

1.
Disconnect mains prior to inspection or making repairs.
2.
DO NOT touch electrical parts of frequency converter when connected to mains. After removing power from mains, wait 40 minutes before touching
any electrical parts. See the label on the front of the frequency converter door for specific discharge time.
3.
The STOP key on the keypad does not disconnect mains.
4.
During operation and while programming parameters, the motor may start without warning. Activate the STOP key when changing data.
1.4 Electrostatic Discharge (ESD)
When performing service, use proper ESD procedures to prevent damage to sensitive components.
Many electronic components within the frequency converter are sensitive to static electricity. Voltages so low that they cannot be felt, seen or heard can reduce
the life, affect performance, or completely destroy sensitive electronic components.
1.5 Unit Size Definitions
AF-600 FP 380-480 VAC Power
kW
@400 VAC
HP
@460 VAC
Unit Size
500
650
61 / 63
560
750
61 / 63
630
900
62 / 64
710
1000
62 / 64
800
1200
62 / 64
1000
1350
62 / 64
Table 1.1: AF-600 FP 380-480 VAC
AF-650 GP 380-480 VAC Power
kW
@400 VAC
HP
@460 VAC
Unit Size
450/ 500
600/ 650
61 / 63
500 / 560
650 / 750
61 / 63
560/ 630
750 / 900
62 / 64
630 / 710
900 / 1000
62 / 64
710 / 800
1000 / 1200
62 / 64
800 / 1000
1200 / 1350
62 / 64
Table 1.2: AF-650 GP 380-480 VAC
AF-600 FP 525-690 VAC Power
kW
@550 VAC
HP
@575 VAC
kW
@690 VAC
Unit Size
560
750
710
61 / 63
670
950
800
61 / 63
750
1050
900
61 / 63
950
1150
1000
62 / 64
1000
1350
1200
62 / 64
1100
1550
1400
62 / 64
Table 1.3: AF-600 FP 525-690 VAC
AF-650 GP 525-690 VAC Power
kW
@550 VAC
HP
@575 VAC
kW
@690 VAC
Frame Size
500 / 560
650 / 750
630 / 710
61 / 63
560 / 670
750 / 950
710 / 800
61 / 63
670 / 750
950 / 1050
800 / 900
61 / 63
750 / 850
1050 / 1150
900 / 1000
62 / 64
850 / 1000
1150 / 1350
1000 / 1200
62 / 64
1000 / 1100
1350 / 1550
1200 / 1400
62 / 64
Table 1.4: AF-650 GP 525-690 VAC
1.6 Ratings Tables
DC Voltage Levels
380-480V &
380-500V units
525-690V units
Inrush Circuit Enabled
370
550
Inrush Circuit Disabled
395
570
Inverter Undervoltage Disable
373
553
Undervoltage Warning
410
585
Inverter Undervoltage Re-Enable (warning reset)
413
602
Overvoltage Warning (w/o Brake)
817
1084
Dynamic Brake Turn-on
810
1099
Inverter Overvoltage Re-Enable (warning reset)
821
1099
Overvoltage Warning (with Brake)
828
1109
Overvoltage Trip
855
1130
