Data Sheet
May 4, 2012
12V Mega TLynx
TM
: Non-Isolated DC-DC Power Modules:
6.0 – 14Vdc Input; 0.8Vdc to 3.63Vdc Output; 30A output
current
LINEAGE
POWER
23
Document No: DS09-003 ver 1.13
PDF Name: APTS030A0X3_ds.pdf
Ordering Information
Table 4. Device Codes
Product codes
Input
Voltage
Output
Voltage
Output
Current
On/Off
Logic
Connector
Type
Comcodes
APTS030A0X3-SRPHZ
6.0 – 14Vdc
0.8 – 3.63Vdc
30A
Negative
SMT
CC109138351
Table 5. Coding Scheme
TLynx
family
Sequencing
feature.
Input voltage
range
Output current Output voltage
Options
ROHS Compliance
AP T
S
030A0
X
-SR
Z
T = with Seq.
S = 6 - 14V
30A
X =
programmable
output
S = Surface Mount
R = Tape&Reel
P = Paralleling
Z = ROHS6
Table 6. Device Options
Option
Device Code Suffix
Current Share
-P
2 Extra ground pins
-H
RoHS Compliant
-Z
