CP2725AC54TE CPL High Efficiency Rectifier
100-120/200-277V
AC
input; Default Outputs: ±54V
DC
@ 2725W, 5V
DC
@ 4W
January 30, 2014 ©2013 General Electric Company. All rights reserved. Page 6
Environmental Specifications
Parameter Min Typ Max Units Notes
Ambient Temperature -40 12 55 13 °C Air inlet from sea level to 5,000 feet.
Storage Temperature -40 85 °C
Operating Altitude 1524/5000 m / ft
Non-operating Altitude 8200/30k m / ft
Power Derating with Temperature 2.0 %/°C 55°C to 75C 14
Power Derating with Altitude 2.0 C/305 m
C/1000 ft
Above 1524/5000 m/ft; 3962/13000 m/ft
max
Acoustic noise 55 dbA Full load
Over Temperature Protection
125/110 °C
Shutdown / restart [internally measured
points]
Humidity
Operating
Storage
5
5 95
95 %
%
Relative humidity, non-condensing
Shock and Vibration acceleration 6 Grms
NEBS GR-63-CORE, Level 3, 20 -2000Hz, min
30 minutes
Earthquake Rating 4 Zone
NEBS GR-63-CORE, all floors, Seismic Zone 4
Designed and tested to meet NEBS
specifications.
EMC
Parameter Criteria Standard Level Test
AC input
Conducted emissions EN55022, FCC Docket 20780 part 15, subpart J
EN61000-3-2
Meets Telcordia GR1089-CORE by a 3dB margin A 0.15 – 30MHz
0 – 2 KHz
Radiated emissions EN55022 A 30 – 10000MHz
AC Input
Immunity
Line sags and
interruptions
EN61000-4-11 B -30%, 10ms
B -60%, 100ms
B -100%, 5sec
Output will stay above 40V
DC
@ full load 25% line sag for 2 seconds
Sag must be higher than 80Vrms. 1 cycle interruption
Lightning surge EN61000-4-5, Level 4, 1.2/50µs – error free A 4kV, common mode
A 2kV, differential mode
ANSI C62.41 - damage free A3 6kV, common & differential
Fast transients EN61000-4-4, Level 3 B 5/50ns, 2kV (common mode)
Enclosure
immunity
Conducted RF fields EN61000-4-6, Level 3 A 130dBµV, 0.15-80MHz, 80% AM
Radiated RF fields EN61000-4-3, Level 3 A 10V/m, 80-1000MHz, 80% AM
ENV 50140 A
ESD EN61000-4-2, Level 3 B 6kV contact, 8kV air
12 Designed to start and work at an ambient as low as -40°C, but may not meet operational limits until above -5°C
13 Output power is derated to 2kW for temperatures higher than 45C and input voltages higher than 285V
AC
.
14 The maximum operational ambient is reduced in Europe in order to meet certain power cord maximum ratings of 70C. The maximum
operational ambient where 70C rated power cords are utilized is reduced to 60C until testing demonstrates that a higher level is acceptable.
