[1651]
Pulse Reference
[1652]
Feedback [Unit]
[1653]
Digi Pot Reference
[1660]
Digital Input
[1661]
Terminal 53 Switch Setting
[1662]
Analog Input 53
[1663]
Terminal 54 Switch Setting
[1664]
Analog Input 54
[1665]
Analog Output 42 [mA]
[1666]
Digital Output [bin]
[1667]
Freq. Input #29 [Hz]
[1668]
Freq. Input #33 [Hz]
[1669]
Pulse Output #27 [Hz]
[1670]
Pulse Output #29 [Hz]
[1671]
Relay Output [bin]
[1672]
Counter A
[1673]
Counter B
[1674]
Prec. Stop Counter
[1675]
Analog In X30/11
[1676]
Analog In X30/12
[1677]
Analog Out X30/8 [mA]
[1678]
Analog Out X45/1 [mA]
[1679]
Analog Out X45/3 [mA]
[1684]
Comm. Option STW
[1685]
Drive Port CTW 1
[1690]
Alarm Word
[1691]
Alarm Word 2
[1692]
Warning Word
[1693]
Warning Word 2
[1694]
Ext. Status Word
[3421]
PCD 1 Read from MCO
[3422]
PCD 2 Read from MCO
[3423]
PCD 3 Read from MCO
[3424]
PCD 4 Read from MCO
[3425]
PCD 5 Read from MCO
[3426]
PCD 6 Read from MCO
[3427]
PCD 7 Read from MCO
[3428]
PCD 8 Read from MCO
[3429]
PCD 9 Read from MCO
[3430]
PCD 10 Read from MCO
[3440]
Digital Inputs
[3441]
Digital Outputs
[3450]
Actual Position
[3451]
Commanded Position
[3452]
Actual Master Position
[3453]
Slave Index Position
[3454]
Master Index Position
