6.2.5 0-** Operation/Display
Parameter
Number
Parameter Description
Default Value
2 Setup
Change During
Operation
Conver-
sion
Index
Type
0 - 03
Regional Settings
[1] US
1 set-up
FALSE
-
Uint8
0 - 04
Operating State at Power-up (Hand)
[1] Forced stop ref=old
All set-ups
TRUE
-
Uint8
0 - 10
Active Set-up
[1] Set-up 1
1 set-up
TRUE
-
Uint8
0 - 11
Edit Set-up
[1] Set-up 1
1 set-up
TRUE
-
Uint8
0 - 12
Link Setups
[20] Linked
All set-ups
FALSE
-
Uint8
0 - 31
Custom Readout Min Scale
0
1 set-up
TRUE
-2
Int32
0 - 32
Custom Readout Max Scale
0
1 set-up
TRUE
-2
Int32
0 - 40
[Hand ] Key on Keypad
[1] Enabled
All set-ups
TRUE
-
Uint8
0 - 41
[Off / Reset] Key on Keypad
[1] Enable All
All set-ups
TRUE
-
Uint8
0 - 42
[Auto ] Key on Keypad
[1] Enabled
All set-ups
TRUE
-
Uint8
0 - 50
Keypad Copy
[0] No copy
1 set-up
FALSE
-
Uint8
0 - 51
Set-up Copy
[0] No copy
1 set-up
FALSE
-
Uint8
0 - 60
Main Menu Password
0
1 set-up
TRUE
0
Uint16
6.2.6 1-** Load/Motor
Parameter
Number
Parameter Description
Default Value
2 Setup
Change During
Operation
Conver-
sion
Index
Type
1 - 00
Configuration Mode
[0] Speed open loop
All set-ups
TRUE
-
Uint8
1 - 01
Motor Control Principle
[1] Adv. Vector Control
All set-ups
FALSE
-
Uint8
1 - 03
Torque Characteristics
[0] Constant torque
All set-ups
TRUE
-
Uint8
1 - 05
Hand Mode Configuration
[2] As mode par 1-00
All set-ups
TRUE
-
Uint8
1 - 20
Motor Power
All set-ups
FALSE
-
Uint8
1 - 22
Motor Voltage
All set-ups
FALSE
0
Uint16
1 - 23
Motor Frequency
All set-ups
FALSE
0
Uint16
1 - 24
Motor Current
All set-ups
FALSE
-2
Uint16
1 - 25
Motor Nominal Speed
All set-ups
FALSE
0
Uint16
1 - 29
Auto Tune
[0] Off
1 set-up
FALSE
-
Uint8
1 - 30
Stator Resistance (Rs)
All set-ups
FALSE
-2
Uint16
1 - 33
Stator Leakage Reactance (X1)
All set-ups
FALSE
-2
Uint32
1 - 35
Main Reactance (Xh)
All set-ups
FALSE
-2
Uint32
1 - 50
Motor Magnetisation at Zero Speed
100%
All set-ups
TRUE
0
Uint16
1 - 52
Min Speed Normal Magnetising [Hz]
0 Hz
All set-ups
TRUE
-1
Uint16
1 - 55
U/f Characteristic - U
All set-ups
TRUE
0
Uint16
1 - 56
U/f Characteristic - F
All set-ups
TRUE
0
Uint16
1 - 60
Low Speed Load Compensation
100%
All set-ups
TRUE
0
Uint16
1 - 61
High Speed Load Compensation
100%
All set-ups
TRUE
0
Uint16
1 - 62
Slip Compensation
100%
All set-ups
TRUE
0
Int16
1 - 63
Slip Compensation Time Constant
0.1 s
All set-ups
TRUE
-2
Uint16
1 - 71
Holding Time
0 s
All set-ups
TRUE
-1
Uint8
1 - 72
Start Function
[2] Coast/delay time
All set-ups
TRUE
-
Uint8
1 - 73
Start Mode
[0] Disabled
All set-ups
FALSE
-
Uint8
1 - 80
Function at Stop
[0] Coast
All set-ups
TRUE
-
Uint8
1 - 82
Min Speed for Function at Stop [Hz]
0 Hz
All set-ups
TRUE
-1
Uint16
1 - 90
Motor Thermal Protection
[0] No protection
All set-ups
TRUE
-
Uint8
1 - 93
Thermistor Resource
[0] None
All set-ups
FALSE
-
Uint8
6.2.7 2-** Brakes
Parameter
Number
Parameter Description
Default Value
2 Setup
Change During
Operation
Conver-
sion
Index
Type
2 - 00
DC Hold Current
50%
All set-ups
TRUE
0
Uint16
2 - 01
DC Brake Current
50%
All set-ups
TRUE
0
Uint16
2 - 02
DC Braking Time
10 s
All set-ups
TRUE
-1
Uint16
2 - 04
DC Brake Cut In Speed
0 Hz
All set-ups
TRUE
-1
Uint16
2 - 10
Brake Function
[0] Off
All set-ups
TRUE
-
Uint8
2 - 11
Brake Resistor (ohm)
All set-ups
TRUE
0
Uint16
2 - 16
AC Brake, Max current
100%
All set-ups
TRUE
0
Uint16
2 - 17
Over-voltage Control
[0] Disabled
All set-ups
TRUE
-
Uint8
2 - 20
Release Brake Current
0 A
All set-ups
TRUE
-2
Uint32
2 - 22
Activate Brake Speed [Hz]
0 Hz
All set-ups
TRUE
-1
Uint16
